Industrial Single Board Computer
-8K@60fps Video Output nrog Dual HDMI 2.1
-Ua-hauv 6 TOPS NPU rau Edge AI Inference
- Txhawb Android / Ubuntu / Debian
-Compact 89 × 57mm Hneev taw - Lub Zog Loj, Loj Loj
Xa kev nug
Product Details ofIndustrial Single Board Computer
Senke Pi5-MAX Ib Leeg Board Computer - Lub Hwj Chim Ua Tau Zoo
Lub Pi5-MAX yog lub siab-kev ua tau zoo ib leeg lub khoos phis tawj siv los ntawm Rockchip RK3588 octa-core 64-ntsis processor, xa mus txog 2.4GHz moos ceev thiab 6 TOPS ntawm NPU-based AI acceleration. Nrog kev sib koom ua ke ARM Mali-G610 GPU, nws txhawb nqa zoo kawg nkaus 8K @ 60fps video tso zis thiab dual HDMI 2.1 cov lus qhia - zoo tagnrho rau digital signage, ntug AI rooj vag, thiab kev siv HMI.
Nruab nrog 2.5G Ethernet, M.2 NVMe SSD qhov, dual USB 3.0, peb MIPI-CSI lub koob yees duab inputs, thiab 40-pin GPIO header tau sib xws nrog tus qauv Raspberry Pi HATs, Pi5-MAX muaj qhov tsis sib haum xeeb nthuav dav.
Txhawb Android 12, Ubuntu 22.04, thiab Debian 12. Muaj nrog 4GB / 8GB / 16GB LPDDR5. Compact 89 × 57mm hneev taw. Zoo meej rau cov neeg tsim khoom thiab cov neeg sib koom ua ke nrhiav cov muaj zog, tus nqi - cov kev daws teeb meem zoo tshaj plaws.
|
Qeb |
Specification |
|
Processor |
Rockchip RK3588 Octa-core 64-ntsis (4 × Cortex-A76 @ 2.4GHz + 4 × Cortex-A55 @ 1.8GHz) |
|
AI Accelerator |
Ua-hauv 6 TOPS NPU rau ntug AI inference |
|
GPU |
ARM Mali-G610 MP4, txhawb 8K@60fps video ua |
|
Nco |
LPDDR5, xaiv tau 4GB / 8GB / 16GB |
|
Cia |
M.2 NVMe SSD (PCIe 3.0 x4, 2280) + MicroSD daim npav qhov + eMMC qhov (yeem) |
|
Video tso zis |
2 × HDMI 2.1 (txog 8K@60fps) + 1 × MIPI-DSI 4-Lane |
|
Lub koob yees duab input |
3 × MIPI-CSI 4-Lane connectors |
|
Ethernet |
1 × 2.5G Ethernet (RTL8125BG) |
|
USB Ports |
2 × USB 3.0 + 2 × USB 2.0 HOST |
|
GPIO Kev nthuav dav |
40-pin GPIO header (tshaj nrog tus qauv Raspberry Pi HATs), txhawb UART, PWM, I2C, SPI, CAN, GPIO |
|
Wireless |
Onboard Wi-Fi 802.11ac/a/b/g/n + Bluetooth 5.2 (AP6256) |
|
Fais fab mov |
Hom -C 5V/5A |
|
Qhov ntev |
89mm × 57mm × 16.2mm |
|
OS Support |
Android 12, Ubuntu 22.04/20.04, Debian 11/12 |
